Product Overview
Front Panel Storage
1
Specifications
To accommodate PC user’s need for more storage flexibility and convenience, SilverStone created a line of front bay storage products
called the FS series. These are 5.25” bay chassis designed to fit 3.5” or 2.5” SAS/SATA drives. Equipped with release handle made out
of finely brushed aluminum, hot-swapping drives is extremely quick and comfortable. Built-in cooling fan behind the chassis ensures
drive and run cool for extended life while individual LED indicators let user easily monitor drive status in one glance. For security, each
drive tray also has metal key lock. For those that need to upgrade their current PC with more drives, SilverStone’s FS series is a great
choice.
FS204 FS208 FS212
Model
Color
Material
Form factor
Drive support
Transfer rate
Host interface
Power connector
Drive tray security
Number of key
LED indicator
Cooling fan
Net weight
Dimension
SST-FS204B, SST-FS208B, SST-FS212B
Black
Aluminum body, tray, and front bezel
5.25” drive bay
2.5” SAS/SATA HDD or SSD
Up to 6 Gbit/s (dependent on drive speed)
7-Pin SATA connector or SAS primary channel connection
SATA 15-Pin
Triangle metal key lock design with guiding rail & anti-vibration
2
Power On
Fan Failure
Over heating
40mm fan x 2, 3500rpm (FS204)
70mm fan x 1, 3000rpm (FS208)
80mm fan x 1, 3000rpm (FS212)
0.67kg (FS204)
1.33kg (FS208)
1.82kg (FS212)
Blue
Red blinking (slower)
Red blinking (faster)
Introduction
Fits 2.5” SAS/SATA 6Gbit/s drives in 5.25” device bay
Individual metal key lock for each drive for extra security
All aluminum body with beautiful hairline brushed finish
Independent drive status LED
Built-in cooling fan for excellent heat dissipation
Compatible with all 2.5” drives up to 14.5mm thickness
Fully supports SATA Hot-Swap function
Special Features
eatures
FS20
more drives, SilverStone’s F
146
X
mm (W) 41.7 mm (H)
X
180mm (D) , FS204
146
X
mm (W) 127mm (H)
X
164mm (D) , FS212
146
X
mm (W) 85 mm (H)
X
159mm (D) , FS208
