TOP COVER
5.25” DRIVE BAY x 2
5.25” DRIVE BAY x 2
3.5” DRIVE BAY x 4
2.5” DRIVE BAY x 2
12025 FAN x 2
BOTTOM SIDE FILTER x 2
3.5” DRIVE BAY x 1
RIGHT SIDE FILTER x 1
12025 FAN x 1
RESET BUTTON
POWER BUTTON
USB 3.0 x 2 + SPK + MIC
LEFT SIDE FILTER x 1
PS2 PSU (OPTION)
ATX MB (OPTION)
12025 FAN x 1 (OPTION)
8025 FAN x 2 (OPTION)
EXPANSION SLOTS x 8
SCREW D
SCREW C
SCREW E
SCREW A
USB CABLE
CABLE TIES
Motherboard standoff
Secure motherboard, PSU, 3.5” drives
Secure 2.5” drives, 5.25” drives (left cage)
Secure 5.25” drives (right cage)
USB 3.0 to USB 2.0 adapter
Cable management
C188-SMT-3P5HDD-
RIGHT-BKT
3.5” hard drive tray
KEY
Lock front door
SCREW WASHER
Motherboard standoff securing tool
SCREW B
Secure 3.5” hard drive tray
