Overall Length - 44’-5”
Overall Length w/Ext. Platform - 47’ - 4 3/4”
Length at Waterline - 35’ - 10 7/8”
Length Fairbody - 42’ - 0”
Beam - 14’ - 10.5”
Beam - Waterline - 12’ - 4”
Draft (Maximum) - 3’ - 8 1/2”
Displacement (dry) - 30,306 lbs.
Displacement (full fl uids) - 35,073 lbs.
Transom Deadrise - 17 degrees
Power Options
Crusader 8.2 & Merc 8.2L
Cummings 370B & 450C
Caterpillar 3126 (350HP, 385HP and 420HP)
VOLVO TAMD74
Fuel Capacity - 400 Gal.
Fresh Water Capacity - 150 Gal.
Waste Water Capacity - 80 Gal.
Water Heater Capacity - 10.5 Gal.
Average Headroom - 6’ - 6”
Maximum Recommended Number of Persons - 14
Maximum Recommended Load - 2,692 lbs
SPECIFICATIONS
