Sim-Lab P1-X - Wheel Deck Setup; Wheel Deck Component Assembly

15
| 15 28
IF YOU PURCHASED THE
SIDE MOUNT,
CONTINUE ON PAGE 17
Corner Bracket
Cap
4X
Corner
Bracket**
4X
M8 X 25
(W8)
8X
Washer M8
(W10)
8X
Wheel Deck
Side Plate Right
1X
Wheel Deck
Side Plate Left
1X
Wheel Deck
1X
W3
W1
W2
W5
W11
W10
W4
W8
