26
| 26 28
BOX A
PROFILE KIT
# Part QTY Note
AP1 160X40 Length=1350mm 2
AP2 160X40 Length=500mm 2
AP3 120X40 Length=780mm 2
BOX C - Pedal Tray
PROFILE KIT
CP1 160X40 Length=470mm 1
CP2 80X40 Length=470mm 1
HARDWARE KIT
C3 P1-X pedal plate LEFT 1
C4 P1-X pedal plate RIGHT 1
C5 Bolt M8 X 25 DIN 912 10
C6 Bolt M6 X 16 DIN 912 12
C7 Bolt M5 X 16 DIN 912 12
C8 Bolt M8 X 25 DIN 7991 10 Countersunk
C9 Washer M8 DIN 125-A 10
C10 Slot-Nut M8 10
C11 Slot-Nut M6 12
C12 Slot-Nut M5 12
Disclaimer: for some entries on this list, we supply more than required as spare
materials. Don’t worry if you have some leftovers, this is intentional.
BOX B
PROFILE KIT
BP1 80X40 Length=580mm 1
BP2 40X40 Length=500mm 2
BP3 40X40 Length=320mm 1
BP4 40X40 Length=200mm 2
HARDWARE KIT
B5 Sandwich plate large 2
B6 Sandwich plate small 1
B7 Rubber Feet 4
B8 Corner bracket 40x40 20
B9 Corner bracket 40x40 cap 20
B10 Profile 160x40 end-cap 4
B11 Profile 120x40 end-cap 4
B12 Profile 80x40 end-cap 1
B13 Profile 40x40 end-cap 9
B14 Bolt M8 X 25 DIN 912 8 Bag HW 40.D
B15 Bolt M8 X 20 DIN 912 10 Bag HW 40.D
B16 Bolt M8 X 16 DIN 912 50 Bag HW 40.C
B17 Bolt M6 X 20 DIN 912 8 Bag HW 40.D
B18 Bolt M6 X 12 DIN 912 4 Bag HW 40.D
# Part QTY Note
B19 Bolt M8 X 25 DIN 7991 12 Countersunk, Bag HW 40.D
B20 Bolt M8 X 20 DIN 7991 20 Countersunk, Bag HW 40.D
B21 Washer M8 DIN 125-A 10 Bag HW 40.D
B22 Slot-Nut M8 65 Bag HW 40.A
B23 Slot-Nut M6 12 Bag HW 40.B
B24 Slot-Nut M5 4 Bag HW 40.D
B25 Slot-Nut M4 4 Bag HW 40.D
