SIMAG SCE 20 - Page 4

c)
5022 / 6022 mm (inch) 7540 mm (inch) 9040 mm (inch) 9550 mm (inch)
A 467 (18 3/8) 535 (21 1/16) 700 (27 1/2) 700 (27 1/2)
B 570 (22 7/16) 600 (23 5/8) 600 (23 5/8) 600 (23 5/8)
C 790 (31 1/8) 910 (35 13/16) 900 (35 7/16) 970 (38 3/16)
SCE 50 - 65
C
A
B
C
A
B
SCE 105
