TECHNICAL DATA 3215 3220 3225 3235 3245 3445 3240 K 3262 3462
AF AF AF AF 3240 K
● = Yes ■ = Option AF
Polycarbonate body. (Isulation Class II) ●●●●●●●●●
Projector weight (without any accessory) 7,1kg 7,1kg 7,1kg 7,1kg 7,1kg 7,7kg 7,2kg 7,2kg 7,8kg
Voltage supply 110-130-220-240V AC +/- 10 % - 50/60 Hz – – –––– ●●●
Voltage supply 230 V AC ( ■ 115 V) +/- 10 % - 50/60 Hz ●●●●●● –––
Fuse for: 220 - 240 V / 230 V T 2 A T 2 A T 2 A T 2 A T 2 A T 4 A T 2 A T 2 A T 4 A
Power consumption (approximately) 350 W 350 W 350 W 350W 350 W 550 W 350 W 350 W 550 W
Automatic thermal overload cut-out / Independent ventilation ●●●●●●●●●
Indépendent and variable ventilation – – ––––– ■■
Halogen lamp 24V - 250 W (50Hours - bottom G6,35-15) 12222–22–
Halogen lamp 36V - 400 W (50Hours - bottom G6,35-15) – – – – – 2 ––2
Electronic regulation ( ● ) or limitation ( ✚ ) of the lamp voltage – – – – ✚✚ – ●●
Reset tray homing – ●●●●●●●●
Autofocus – – ●●●● 3240 AF – –
"TIMER" function (automatic slide change) – –
●●●●●●●
“AUTOSHOW” function (timer+ Homing when no slide in the gate) – – ●●●●●●●
A-L-C (Automatic Lampe Change) – – – – ●●●●●
N.S.N.L (No Slide, No Light) / ✱ = + (A.C.D.) “Auto Cooling Delay”– ●●●●●●✱✱
RS232 serial line..(6 pin plug) – – – – ●●●●●
DRA - S - K - U Mode selector – – ––––– ●●
Rapid slide selection (RARO) ●●●●●●●●●
Lamp power controlled by built-in “TRIAC”––– ●●● – ●●
Screws (3) for hard fixing of the machine – – –––– ●●●
————— OVERVIEW —————
1 Slide gate ●●●●●●●●●
2Tray locking ●●●●●●●●●
3 Tray drive ●●●●●●●●●
4 Zero position tray sensor ●●●●●●●●●
5 Lamp and condenser aperture ●●●●●●●●●
6 Focusing knob (lens position, reference, indication) ●●●●●●●●●
7 Slot for lens accessories ●●●●●●●●●
8 Screw-feet (vertical adjustment) ●●●●●●●●●
9 Telescopic front feet ●●●●●●●●●
10 Lens holder Ø 52,5 mm Hélical and rack-mounted lens ●●●●●●●●●
11 Fixed carrying handle ●●●●●●●●●
12 Forward button ●●●●●●●●●
13 Reverse button ●●●●●●●●●
14 Bright / economy lamp switch – – – ●●●●●●
15 Internal / External lamp switch (In / Out) – – – ●●●●●●
16 Audio-visual DIN 12 pin plug or 14 pin plug – – – 14 ––12 (1) 12 (2) 12 (2)
17 DIN 6 Plug ●●●●●●●●●
17 bSUB D9 “RS232” Plug – – – – ●● –––
18 Main fuse holder ●●●●●●●●●
19 CEE Main plug (Class II, no earth) ●●●●●●●●●
20 On / Off switch ●●●●●●●●●
21 LED button: TIMER / AUTOSHOW mode – – ●●●●●●●
22 LED button: FOCUS mode – – ●●●●●●●
23 Ventilation grill ●●●●●●●●●
24 LED panel: modes and defaults – – ––––– ●●
25 Manual rapid lamp change – – ●●●●●●●
26 Horizontal adjustment Lamp 2 – – ●●●●●●●
27 Vertical adjustment Lamp 1 and 2 ●●●●●●●●●
28 Horizontal adjustment Lamp 1 – – ●●●●●●●
————— LED PANEL INFORMATION —————
30 Yellow LED projector drive command modes – – ––––– ●●
31 Red LED When slide changing – – ––––– ●●
32 Green LED for “0” tray position – – – ●●● – ●●
33 Yellow LED when using Lamp 2 – – – – ●● – ●●
34 Yellow LED : RS232 communication function – – ––––– ●●
