15
Model
ECOMAXI VB 300、ECOMAXI VB 300 S
Operational mode
Heat pump, Automatic and Boost mode
Power supply
220-240V~ 50Hz
Max. power input (under boost mode)
2400W
Max. current input (under boost mode)
10.43A
Heat pump
Max. power input
900W
Heating up time
8:00(h:min)
Refrigerant
R134a/650g
Declared load profile
XL
COPDHW
2,972
(1)
3,677
(2)
Mixed water at 40℃
403,8L
(1)
398,4L
(2)
Energy efficiency
125,5%
(1)
154,7%
(2)
Energy efficiency class
A+
(1)
A+
(2)
Annual electrical consumption
1335kWh
(1)
1083kWh
(2)
Max. outlet water temp.
65℃ (default 52℃)
Operating temp. range
-7℃～43℃
Electric
heating
Rated power input
1500W
Max. outlet water temp.
75℃
Max. operating pressure for refrigerant
circuit (discharge side/suction side)
2.4MPa/0.6MPa
Storage
tank
Rated capacity
300L
Max. operating Pressure
1.0MPa
Water inlet/outlet
DN20
Solar energy inlet/outlet
DN20
Anti-electric shock class
Class Ι
Sound power level
(3)
58dB (A)
Net weight(kg)
121
136
Dimensions(mm)
φ662*1970
Note (1): Performance condition：ambient air 7°C DB/ 6°C WB, incoming/final water temperature 10°C /
52°C, according to EN 16147:2017, (EU) NO 814-2013.
Note (2): Performance condition：ambient air 14°C DB/ 13°C WB, incoming/final water temperature
10°C / 52°C, according to EN 16147:2017, (EU) NO 814-2013.
Note (3): Sound power level tested with air duct, according to EN 12102-1-2017, ISO 3744:2010.
ATTENTION
The parameters in the above table are only for reference. When the contents of this table differ
from those of the nameplate on the appliance, please refer to the nameplate.
