20
PELLET BURNER AND LOADER2.4.5
Fig. 44
Burner
Screw feeder
Loading aperture
Screw feeder motor
Flexible connection tube
BOILER AND PELLET CONTAINER ASSEMBLY2.4.6
Fig. 45
Screw feeder
Burner
Self-extinguishing
flexible tube
SOLIDA PL boiler
Control panel
Power pack with
screw feeder motor
80-kg pellet container
