30
On the bottom line the name of the currently displayed function appears; if the text is too long the line will be scrolled up to the end of the text. The
items follow the order shown in Table 12.
Menu Submenu Values
General Settings Stove Type Stove type name
Reset Service Time Hours elapsed since the last maintenance
operation
Pellet Level Sensor On / Off
Eco Menu Waiting On 0 ÷ 30 min
Waiting Off 0 ÷ 30 min
Delta Temp. 0 ÷ 10 °C
Pellet Feeder Menu Pellet Feeder Brake (fuel feeder motor quick
stop option)
On / Off
Duration at Min Power (on time @ min. pw.) 0.10 ÷ 12.00 sec ** (step 0.05sec)
Duration at Max Power (on time @ max. pw.) 0.10 ÷ 12.00 sec **(step 0.05sec)
AUX. Output (2nd fuel feeder device) On / Off
Periods Ratio (on/off duty cycle) 1 ÷ 100
Percentage Factor (on time correction) -10 ÷ +100
Combustion Airflow Menu RPM Control On / Off
Airflow at Min Power 0 ÷ 400 lpm
Airflow at Max Power 0 ÷ 400 lpm
RPM Min Power 300 ÷ 2750 rpm
RPM Max Power 300 ÷ 2750 rpm
Motor Type 0 ÷ 3
Second Extractor Menu Enable On / Off
Ignition 1 0 ÷ 30
Ignition 2 0 ÷ 30
Shut down 1 0 ÷ 30
Shut down 2 0 ÷ 30
Level 1 *** 0 ÷ 30
Level 5 *** 0 ÷ 30
Hydro Menu Hydro Mode On / Off
Water Pressostat On / Off
Max Water Pression 2,5 ÷ 4,7 Bar
Accumulator (water storing tank) On / Off
Modulating Pump (on/off temp. dependent
timed mode of operation)
On / Off
Temp. On Pump 40 ÷ 80 °C
Secondary Fluxmeter On / Off
Hydro Shutdown On / Off
Hydro Independent On / Off
Water Temp. Hysteresis 4÷ 15
Sanitary Gain (H.D.W. temp. control loop gain) -10÷ +10
Ignition Menu Fumes Temp. On (heater fired up smoke temp.
threshold)
0 ÷ 150 °C
Fumes Temp. Off (smoke shutdown end temp.
threshold)
10 ÷ 290 °C
Pre-Startup 1 Duration (warm-up time 1) 0 ÷ 300 sec
Pre-Startup 2 Duration (warm-up time 2) 0 ÷ 300 sec
Warm Pre-Startup Duration (firing up time with
a still hot heater)
0 ÷ 300 sec
Ignition Duration 0 ÷ 3600 sec
Fire On Duration 0 ÷ 3600 sec
Photoresistor On / Off
Alarm Menu Combustion Airflow Pre-Alarm Duration 180 ÷ 14400 sec
