SimLab P1-X - Main Kit Parts List

Parts list - Main kit
10
BOX A
Base profiles
Part No. Part name QTY UoM Note
A1 Profile 40mm slot 8 (Black, 40x160L) - 1350mm 2 Units
A2 Profile 40mm slot 8 (Black, 40x160L) - 500mm 2 Units
A3 Profile 40mm slot 8 (Black, 40x120L) - 780mm 2 Units
BOX B
Hardware kit
Part No. Part name QTY UoM Note
B1 Cover cap for corner bracket (40x40) 20 Units
B2 Rubber feet 4 Units
B3 End cap profile (40x40L) 9 Units
B4 End cap profile (40x80L) 1 Units
B5 End cap profile (40x120L) 4 Units
B6 End cap profile (40x160L) 4 Units
B7 Slot 8 nut (M8) 65 Units
B8 Slot 8 nut (M6) 12 Units
B9 Slot 8 nut (M4) 4 Units
B10 Slot 8 nut (M5) 4 Units
B11 Washer (Black steel, M8, Plain black) 10 Units
B12 Sandwich plate small 40x40 1 Units
B13 Bolt - DIN 912 (Black steel, 16mm, M8) 50 Units
B14 Bolt - DIN 912 (Black steel, 20mm, M6) 8 Units
B15 Bolt - DIN 7991 (Black steel, 25mm, M8) 12 Units
B16 Bolt - DIN 7991 (Black steel, 20mm, M8) 20 Units
B17 Bolt - DIN 912 (Black steel, 25mm, M8) 8 Units
B18 Bolt - DIN 912 (Black steel, 20mm, M8) 10 Units
B19 Bolt - DIN 912 (Black steel, 12mm, M6) 4 Units
B20 Profile 40mm slot 8 (Black, 40x40L) - 500mm 2 Units
B21 Profile 40mm slot 8 (Black, 40x40L) - 320mm 1 Units
B22 Profile 40mm slot 8 (Black, 40x40L) - 200mm 2 Units
B23 Profile 40mm slot 8 (Black, 40x80L) - 580mm 1 Units
B24 Corner bracket (40x40) 20 Units
B25 Sandwich plate large 2 Units
BOX C
P1-X pedal tray
Part No. Part name QTY UoM Note
C1 Slot 8 nut (M5) 12 Units
C2 Slot 8 nut (M6) 12 Units
C3 Slot 8 nut (M8) 10 Units
C4 Washer (Black steel, M8, Plain black) 4 Units
C5 Bolt - DIN 912 (Black steel, 16mm, M6) 12 Units
C6 Bolt - DIN 7991 (Black steel, 25mm, M8) 10 Units
C7 Bolt - DIN 912 (Black steel, 25mm, M8) 10 Units
C8 Bolt - DIN 912 (Black steel, 16mm, M5) 12 Units
C9 Profile 40mm slot 8 (Black, 40x160L) 2x M8 Thread - 470mm 1 Units
C10 Profile 40mm slot 8 (Black, 40x80L) 2x M8 Thread - 470mm 1 Units
C11 P1-X pedal plate [Left] 1 Units
C12 P1-X pedal plate [Right] 1 Units
