TECHNICAL DATA
BORE 70mm
STROKE 60mm
DISPLACEMENT 230.8 cc
COMPRESSION RATIO 10.1 / 1
Weight ready to fly 19.3 kg
CONSUMER A 5000 rpm 3litres/hour
POWER 7000 rpm 33hp
STATIC THRUST Over 90Kg
Lamellar intake with Walbro Carburetor WB39
Aluminum cylinder with ceramic coating magnesium,
Exhaust resonance
Poly-V belt reduction
Electronic ignition
Electric start
Alternator battery charger in flight
Lubrication premix: 2.5% with premium-grade gasoline
3.0% with unleaded fuel
REDUCTION RATIO AVAIABLE
1:230 Crown gear 129 mm / Pinion 56 mm
1:234 Crown gear 129 mm / Pinion 55 mm
1:242 Crown gear 129 mm / Pinion 53,5 mm
1:3 Crown Gear 138 mm /Pinion 44 mm
