SIMONINI MINI 2 - Tightening Torques

Page 5
MINI2PLUS/01
RECTIFIER RE-CHARGE BATTERY
MINI2PLUS/36
BEARINGS SPACER
MINI2PLUS/02
COIL
MINI2PLUS/37
PULLEY SEEGER
MINI2PLUS/03
KIT SCREWS FOR HEAD (4)
MINI2PLUS/38
ECCENTRIC PINION
MINI2PLUS/04
CYLINDER HEAD
MINI2PLUS/40
KIT SEALS ( 2 )
MINI2PLUS/05
CYLINDER HEAD GASKET
MINI2PLUS/41
KIT BEARINGS FOR CRANKCASE ( 2 )
MINI2PLUS/06
KIT SCREWS FOR CYLINDER (4)
OLD TYPE 4304-6304/C3 - NEW 4205-6205/C3
MINI2PLUS/07
CYLINDER
MINI2PLUS/42
COMPLETE CRANKSHAFT AND ROD
MINI2PLUS/08
CYLINDER GASKET
MINI2PLUS/45A
COMPLETE CONNECTING ROD (new type 22mm)
MINI2PLUS/09
KIT SILENT-BLOCKS (4)
MINI2PLUS/46
COMPLETE PISTON AND RINGS
MINI2PLUS/10
CRANK CASE
MINI2PLUS/46A
TWO RINGS
MINI2PLUS/11
KIT ENGINE SCREWS
MINI2PLUS/46B
PISTON PIN
MINI2PLUS/12
WASHER-PRESSURE OUTLET
MINI2PLUS/46C
SET PISTON CIRC CLIP
MINI2PLUS/15
AIR FILTER
MINI2PLUS/47
STATOR
MINI2PLUS/17
CARBURETTOR WALBRO WB 37
MINI2PLUS/49
FLY- WHEEL
MINI2PLUS/17A
ALUMINIUM MANIFOLD
MINI2PLUS/50
ALUMINIUM PLATE FOR STATOR
MINI2PLUS/17B
PLASTIC MANIFOLD
MINI2PLUS/51
LITTLE PINION FOR REDUCTION
MINI2PLUS/17C
PAPER GASKET FOR CARBURETOR
MINI2PLUS/52
SPARK PLUG BR 10 ES
MINI2PLUS/17D
ALUM. MANIFOLD FOR AIR FILTER
MINI2PLUS/53
ALUMINIUM PLATE FOR COIL
MINI2PLUS/20
CARBURETTOR RUBBER MANIFOLD
MINI2PLUS/54
EXHAUST SYSTEM
MINI2PLUS/21
REED VALVE
MINI2PLUS/54A
EXHAUST BEND
MINI2PLUS/22
REED VALVE GASKET
MINI2PLUS/54B
SILENCER
MINI2PLUS/23SIL
ELECTRIC STARTER SILVER
MINI2PLUS/54C
INOX/SILICON CLAMP
MINI2PLUS/23G OL
ELECTRIC STARTER GOLD
MINI2PLUS/54D
EXHAUST CHAMBER
MINI2PLUS/26SIL
CROWN GEAR SILVER
MINI2PLUS/55
ALUMINIUM PLATE FOR SILENT-BL OCK
MINI2PLUS/26G OL
CROWN GEAR GOLD
MINI2PLUS/58
RUBBER FOR SPARK PLUG
MINI2PLUS/27
WASHER FOR PINION
MINI2PLUS/59
CONNECTING ROD CAGE
MINI2PLUS/28
NUT FOR PINION AND FLY-WHEEL
MINI2PLUS/60
EXHAUST GASKET
MINI2PLUS/29
POLY- V BELT
MINI2PLUS/61
COMPLETE GASKET KIT
MINI2PLUS/30
ALUM. PLATE FOR PROP. +SCREWS
MINI2PLUS/62
EXHAUST MANIFOLD AND SPRINGS
MINI2PLUS/32
SCREW FOR BIG PULLEY
MINI2PLUS/63
KIT MEMBRANE WALBRO WB32/37
MINI2PLUS/33
BIG PULLEY
MINI2PLUS/64
LITTLE WHITE MEMBRANE WB32/37
MINI2PLUS/33A
BIG PULLEY for 1:3
MINI2PLUS/65
REED VALVE PETAL
MINI2PLUS/34
PULLEY SPACER
TIGHTENING TORQUES
Description
Special number in table
NM
Kgf.m
Head Nut
3
22
2.2
6x40 Screws
11
12
1.2
Connector
12
10
1.0
6x30 Screws
18
12
1.2
6x25 Screws
25
10
1.0
12 Nuts
28
54
5.4
12x30 Screws
32
60
6.0
8x40
39
24
2.4
Spark Plug
52
18
1.8
