Simoniz 39-9027-4 - Parts List

16
WARNING: When servicing, use only SIMONIZ
®
replacement parts. Use of any
other parts may create a HAZARD or cause damage to your Buffer/Polisher.
Any attempt to repair or replace electrical parts on this Buffer/Polisher may create a
hazard unless repair is performed by a qualified technician.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
162851
Fuse assembly
1
2
500000
Tapping screw ST2.9x9
1
3
160205
UL cord set
1
4
322015
Cord guard
1
5
315000
Cord clamp
2
6
500201
Tapping screw ST3.9x14
2
7
317009
Switch button
1
8
224451
Switch retainer
1
9
500200
Tapping screw ST3.9x19
11
10
321000
Rubber cap
2
11
163633
ON/OFF switch
1
12
163100
Rectifier
1
13
300075
Housing
1
14
318011
Base plate
1
15
145026
Foam pad
1
16
221264
Plain washer 8
1
17
215099
Bolt
1
18
520017
Bearing 608-2Z
4
19
205559
Metal sleeve
2
20
234803
Counterbalance
1
21
138007
Stator
1
22
134007
Rotor
1
23
222826
Brush holder
2
24
162426
Carbon brush
2
25
314526
Brush holder support
2
26
314512
Brush cap
2
PARTS LIST – MODEL 39-9027-4
!
