Simoniz 39-9049-2 - Page 20

20
WARNING: When servicing, use only SIMONIZ
®
replacement parts. Use of any
other parts may create a HAZARD or cause damage to your 12 V Cordless Random
Orbit Polisher/Sander.
Any attempt to repair or replace electrical parts on this 12 V Cordless Random Orbit
Polisher / Sander may create a hazard unless repair is performed by a qualified
technician.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
163688
Switch
1
2
500201
Screw
4
3
306098
Left housing
1
4
656000
12 V Adaptor
1
5
310566
Back cover
1
6
242555
Fixing steel wire
1
7
654503
Battery pack
2
8
222251
Conducting strip
4
9
152005
Contact plate
1
10
N/A
Lead wire
2
11
130032
Motor
1
12
200058
Motor gear
1
13
202011
Oil-retaining bearing
1
14
232509
Gear box
1
15
340011
Sealing ring
1
16
312136
Gear box cover
1
17
500209
Screw
4
18
200059
Gear
1
19
202712
Shaft
1
20
520026
Bearing
1
21
321025
Vibration reduction ring
1
22
341016
Hook & loop pad
1
23
341017
Sponge pad
1
24
145036
Base plate
1
25
520040
Bearing
1
26
225337
Bearing cover
3
27
203057
Counterbalance
1
28
500801
Screw
2
29
236033
Gearbox cover
1
30
306098
Right housing
1
31
JM-15U
Charger
1
32
CLQ035-12
Charging stand
1
33
164301
12 V Adaptor cord
1
PARTS LIST – MODEL 39-9049-2
!
