NOTE
You must place the ribbon cable loop crossways directly under the thumb-
turn lid.
5. Reattach lid to the outer thumb-turn and press gently.
9 The lid is now flush against the outer thumb-turn.
6. Use the battery replacement key to lock the bayonet mount to a min-
imum extent until the lid locks into the outer lid of its own accord.
(about 1° in a clockwise direction)
7. Re-attach outer thumb-turn onto the locking cylinder.
9 The outer thumb-turn is now flush against the locking cylinder.
8. Now use the battery replacement key to lock the bayonet mount com-
pletely. To do so, face the outer thumb-turn and place the battery re-
placement key on the bayonet mount and turn in an anti-clockwise dir-
ection until the thumb-turn is firmly in position.
9. Check that the outer thumb-turn is firmly attached again and test the
locking cylinder function to ensure that it works.
Digital Locking Cylinder 3061
(Manual)
8. System 3060 battery replacement
42 / 54
