VISUAL TOUR
3
HDD Activity LED (Blue)
Flashes to indicate disk drive read/write activity.
Power LED (Red)
Illuminates when SimpleDrive is receiving power.
DC-IN Jack
JackSocket for connecting an AC power adapter to
SimpleDrive.
Mini USB Socket
Mini-B USB socket for connecting SimpleDrive to your
computer.
USB/AUX PWR Cable
Use this cable to connect SimpleDrive your
computer.
• Mini-B USB plug
Connects to SimpleDrive to provide signal and
USB bus power source to SimpleDrive.
• Type A USB plug (Power and signal)
Connects to a USB port on your computer to provide
signal and USB bus power source to SimpleDrive.
• Type A USB plug (Power only)
Connects to a USB port on your computer to provide a
secondary USB bus power source to SimpleDrive.
