6
Press the Setup Directory key <F3> to enter the terminal’s configuration mode.
Setup Directory <F3>: For <F1> through <F14> select menus, use arrow
keys to select field. Press the Return key to change parameter.
Quick Setup <F1>
Command Specification
Emulation VT300/7
EIA Baud Rate 9600*
EIA Data Format 8/1/E*
Enhanced ON
AUX Baud Rate 9600*
AUX Data Format 8/1/E*
Comm Mode Full Duplex
Language U.S.
Sessions One
Host/Printer EIA/AUX
General Setup <F2>
Command Specification
Emulation VT300/7
Enhanced ON
Auto Wrap OFF
Auto Font Load ON
Auto Page OFF
Curs Dir Left to Right
Auto Scroll ON
Monitor Mode OFF
Screen Saver OFF
Bell Volume 06
Warning Bell ON
Bell Length 350 ms
Setup Language U.S.
Sessions One
Display Setup <F3>
Command Specification
Display Cursor ON
Cursor Blink Block
Auto Adjust Cursor ON
Page Length 25
Screen Length 26 lines
Screen Video Normal
Columns 80
Scroll Jump
Overscan Borders ON
Width Change Clear OFF
Speed Fast
Refresh Rate 71 Hz
Keyboard Setup <F4>
Command Specification
Language U.S.
Char Set National
Key Mode ASCII
Key Click ON
Key Repeat OFF
Key Rate 20 cps
Margin Bell OFF
Key Lock Caps
Caps Lock Toggle
Num Lock Toggle
*4100+/4120 values are shown. The 2120 values are as follows: Baud rate = 1200, Data/Parity bits = 8/1None, Parity Check = OFF.
Note: 4010 and 4020 values typically match 4100+/4120 values, but the 4010’s parity setting is NONE.
Continued on next page
Terminal Configurations
Configuring the Terminal
for 2120, 4010, 4020, and
4100+/4120 Systems
