Simplex 4190-9006 User Manual

7
Keys Setup <F5>
Command Specification
Enter Key <cr>
Return Key <cr>
Backspace <BS>/<DEL>
Compose Key Compose
Disconnected Shift-F5
,,and.. ,,and..
‘Key~ ‘and~
<>key <and>
F1 to F5 Keys Local
Desk ACC
Ctrl←
Pound Key U.S.
UDKS Emul Dependent
Ports Setup <F6>
Command Specification
EIA Baud Rate 9600*
EIA Data Format 8/1/E*
EIA Parity Check ON*
Aux Baud Rate 9600*
Aux Data Format 8/1E*
Aux Parity Check ON*
EIA XMT No Protocol
EIA RECV No Protocol
EIA XMT PACE Baud
AUX XMT No Protocol
AUX RECV No Protocol
AUX XMT PACE Baud
Host Setup <F7>
Command Specification
Comm Mode Full Duplex
Local OFF
Null Suppress OFF
Break 250 ms
Modem Control OFF
Disconnect 2 Seconds
Recv <cr> <cr>
Recv <DEL> Ignore
Send Ack ON
Alt Input Data ON
Send Block Term None
Send Region Term Screen
Send End Region
Print Setup <F8>
Command Specification
Print Mode Auto
Print National
Print Region Screen
Print Block Term None
Secondary Recv ON
*4100+/4120 values are shown. The 2120 values are as follows: Baud rate = 1200, Data/Parity bits = 8/1/None, Parity Check = OFF.
Note: 4010 and 4020 values typically match 4100+/4120 values, but the 4010’s parity setting is NONE.
Continued on next page
Terminal Configurations, Continued
Configuring the Terminal
(Continued)
