6 S4100-0103 5/2013
Audio Expansion Signal Module and Options
Model Description Details and Mounting Reference
4100-5116
Expansion Signal Module; three, 1.5 A Class B NACs for
Audio applications; up to five maximum per amplifier;
NAC rating = 1.5 A, 50 W, or 100 speakers maximum
Converts one NAC input to three NAC outputs; selects between two
inputs; for Flex-35/50 amplifiers only, two input NACs are required;
Single Block module mounts in expansion bay;
Supv = 20 mA; Alarm = 80 mA
4100-1266
Expansion Signal Module NAC Expander; NAC rating =
1.5 A, 50 W, or 100 speakers max.
Expands module capacity to six, Class B NACs;
Supv = 0.84 mA; Alarm = 60 mA
These modules
mount on the
4100-5116;
select one
max. per
4100-5116 as
required
4100-1267
Expansion Signal Module Class A Adapter; NAC rating =
1.5 A, 50 W, or 100 speakers maximum
Converts 3 Class B, NACs to Class A;
Supv = 0 mA; Alarm = 30 mA
4100-1268
Expansion Signal Module Constant Supervision Adapter;
Converts 3 Class B NACs to Constant Supervision
Class B or Class A NACs; for 25 or 70.7 VRMS audio
NAC rating = 1.4 A, 50 W, or 100 speakers max.;
Supv = 38 mA on batteries (constant supervision
deactivated); Alarm = 70 mA
General Audio Options
Model Description
4081-9018 End-of-line resistor harness for 70.7 VRMS NACs; 10 k, 1 W
4100-2320 Audio Bay-to-Bay Interconnection Harness Kit; order one for each audio bay addition
4100-0637 Audio Box Interconnection Harness Kit; order one for each close-nippled audio cabinet
Addressable Interface Modules
Model Description Supv. Alarm
4100-3108
IDNet 1+ Module, 250 point capacity with
isolated output, 1 block
With 250 IDNet devices, and 20 device LEDs in alarm 292 mA 510 mA
Module without devices 92 mA 115 mA
Loading per IDNet device (no LEDs on) 0.8 mA 1 mA
4100-3107
Quad IDNet Isolator Module; converts a single connected SLC into four isolated outputs selectable as
Class A or Class B, provides advanced diagnostics for use with retrofit wiring; dual horizontal block
module; (see data sheet S4100-0046 for additional details)
NOTE: This module is compatible with IDNet Remote Isolators
75 mA 115 mA
Relay Modules; Nonpower-Limited
Model Description Resistive Ratings Inductive Ratings Size Supv. Alarm
4100-3202 4 DPDT w/feedback 10 A 250 VAC 10 A 250 VAC 2 Slots 15 mA 175 mA
4100-3204 4 DPDT w/feedback 2 A 30 VDC/VAC ½ A 30 VDC/120 VAC 1 Block 15 mA 60 mA
4100-3206 8 SPDT 3 A 30 VDC/120 VAC 1 ½ A 30 VDC/120 VAC 1 Block 15 mA 190 mA
Current Calculation Notes:
1. For total supervisory current, add panel module currents to base system value and add all external panel-powered loads.
2. For total alarm current, add panel module currents to base system alarm current and add all panel SLC/NAC loads and all external
loads powered from panel power supplies.
Input Power
Enhanced Power Supplies,
EPS/EPS+
120 VAC Models
4.6 A maximum @ 102 to 132 VAC, 50/60 Hz
220-240 VAC Models
2.3 A maximum @ 204 to 264 VAC, 50/60 Hz;
separate taps for 220/230/240 VAC
Expansion Power Supply (XPS)
100 W Amplifiers
120 VAC Models 4 A maximum @ 102 to 132 VAC, 60 Hz
220-240 VAC Models
2 A maximum @ 204 to 264 VAC, 50/60 Hz;
separate taps for 220/230/240 VAC
Power Supply Output
Ratings for EPS/EPS+
Total Power Supply
Output Rating
Including module currents and auxiliary power outputs; 9 A
total for “Special Application” appliances
Output switches to
battery backup
during mains AC
failure or brownout
conditions
IDNAC Output Voltage Regulated 29 VRMS
Auxiliary Power Tap 2 A maximum
Power Supply Output
Ratings for XPS
(nominal 28 VDC on AC;
24 VDC on battery
backup)
Total Power Supply
Output Rating
9 A total including module currents and auxiliary power
outputs
Auxiliary Power Tap 2 A maximum
Rated 19.1 to 31.1 VDC
NACs Programmed
for Auxiliary Power
2 A maximum per NAC;
5 A maximum total
Compatible Special Application Appliances
Simplex TrueAlert ES and TrueAlert addressable notification appliances; contact your
Simplex product representative for compatible appliances
Battery Charger
Ratings for EPS/EPS+
(sealed lead-acid
batteries)
Battery capacity range
UL listed for battery charging of 6.2 Ah up to 115 Ah (batteries larger than 50 Ah
require a remote battery cabinet); ULC listed for charging up to 50 Ah batteries
Charger characteristics
and performance
Temperature compensated, dual rate, recharges depleted batteries within 48 hours per
UL Standard 864, to 70% capacity in 12 hours per ULC Standard S527
Environmental
Operating Temp. Range 32° to 120°F (0° to 49° C)
Operating Humidity Range Up to 93% RH, non-condensing @ 90° F (32° C) maximum
Installation Instruction Reference 574-844, Transponder Interface Cards 579-343, Local Mode Controller
MINIPLEX Transponder Product Selection (Continued)
General Specifications
