The SmartFilter should be installed on a concrete pad at the
desired location, then wired to the power source and any other
sensors or system integration connections.
i
nStalling
wiring
The SmartFilter must
be completely wired
prior to applying pow-
er. Failure to follow
the wiring information
and guide may result
in product damage and
loss of warranty cover-
age. If requested, startup
services can be provided
by Simplex Onsite, Inc.
or Simplex, Inc. to check
field wiring before ap-
Conduit
Entry Area
PUMP
OUTLET
i
nStalling
Control power
i
nStalling ball
valveS
plying power as well as assuring proper operation.
To bring cabling into the SmartFilter, pull a hole into the
cabinet in the Conduit Entry Area (see ) and install a
3R-rated conduit connector for access.
To install control power, connect a primary 120VAC, 60Hz,
30-amp power source to the SmartFilter’s TB-PS-1-2. Ensure
power source and SmartFilter are properly grounded.
Ensure that the Manual Override Switches on each ball valve
are set to “(A) Auto.” (See
.)
8 — Installation
Connect the two cables provided with Motorized Ball Valve
1 to the SmartFilter controller as follows (see
for wire assignments:)
1.
Neutral to TB-MBV-1
2.
Open Valve to TB-MBV-10
3.
Close Valve to TB-MBV-11
4.
Actuator Ground to TB-MBV-4
5.
Ground to TB-MBV-5
6.
Valve Opened to TB-MBV-12
7.
Valve Closed to TB-MBV-13
8.
Status Common t
