Simplex TrueAlert 4906-9228 - IDNAC SLC and Addressable Wiring; IDNAC SLC Operation Advantage (Contd); TrueAlert Addressable Wiring Isolator; TrueAlert Addressable Diagnostics

IDNAC SLC Operation Advantage (Cont’d)
Reduced current allows efficient IDNAC SLC
operation. With IDNAC SLCs, a constant 29 VRMS
source voltage is maintained, even during battery standby,
allowing strobes to operate at higher voltage with lower
current and ensuring a consistent current draw and voltage
drop margin under both primary power and secondary
battery standby. Efficiencies include wiring distances up
to 2 to 3 times farther than with conventional notification,
or support for more appliances per IDNAC SLC, or use of
smaller gauge wiring, or combinations of these benefits,
all providing installation and maintenance savings with
high assurance that appliances that operate during normal
system testing will operate during worst case alarm
conditions.
Reducing Installation and Testing Time. With
separate controls on the same two-wire SLC, installation
time and expense for both retrofit and new construction
can be significantly reduced. When Class B wiring is
used, wiring can be “T” tapped, allowing more savings in
distance, wire, conduit (size and utilization), and overall
installation efficiency. Use of the magnet test feature
improves installation efficiency. TrueAlert device reports
conveniently identify information about each connected
appliance.
TrueAlert Addressable Wiring Isolator
Isolator Model 4905-9929 is available for remote
mounting on TrueAlert addressable circuits to isolate
short circuited wiring from functioning wiring. (Refer to
data sheet S4905-0001 for additional information.)
TrueAlert Addressable Diagnostics
Test Features. Controllers can be selected to pulse each
appliance’s LED when it receives a supervision poll.
When the controller is selected for diagnostic mode, the
appliance magnet test feature provides a response at the
individual appliance being tested.
Silent Appliance Magnet Test. In this test mode, in
response to the magnet test, the appliance LED pulses
sequentially to conveniently indicate the appliance’s
address.
Operational Appliance Testing. In this test mode,
after the address is indicated by pulsing the appliance
LED, the strobe will briefly flash and the horn will briefly
sound to indicate proper operation.
TrueStart Instrument Two (TSIT). The 2nd generation
of the Simplex TrueStart Test Instrument adds testing of
IDNAC SLC wiring and TrueAlert (and TrueAlert ES)
appliances to its ability to test IDCs, NACs, and IDNet
communications before connection to the control panel.
Please contact your local Simplex representative for
additional information.
2 S4906-0005-3 5/2013
Service Port
P
age 1
REPORT 5 : TrueAlert Device Report
1
2:34:56am MON
2
0
-
M
ay
-
1
3
POINT ID CUSTOM LABEL
DEVICE
T
YPE CANDELA
T14-1-1 Location Label . . . up to 40 charact
e
rs
V
/O 15
T14-1-2 Break Room 5
A
/V 110
T14-1-3 Boiler Room
A
/V 75
T14-1-4 Elec. Room 7
A
/V 30
Multi-Candela Ceiling Mount Addressable A/Vs
Model
Housing
Color
“FIRE”
Lettering
Description Dimensions
4906-9228 Red White
Addressable Horn with Multi-Candela Strobe;
intensity selectable as: 15, 30, 75, or 110
candela
4 ¾ L” x 6 ⅞” W x 2 ⅝” D
(121 mm x 175 mm x 67 mm)
4906-9230 White Red
Wire Guards and Ceiling Mount A/V Adapter
Model Description Dimensions
4905-9927* Red Wire Guard for mounting to flush mounted electrical box
8 ½” x 6 ⅛” x 3”
(216 mm x 156 mm x 76 mm)
4905-9928* Red Adapter Plate, required for surface mount guard 9” x 7” (229 mm x 178 mm)
4905-9915 White
Surface Mount Adapter Box Extension, use to cover 1-1/2”
deep surface mounted boxes
4 ¾" x 6 ⅞" x 1 ½" deep,
(121 mm x 175 mm x 38 mm)
4905-9916 Red
* UL listed by Space Age Electronics Inc.
Product Selection
TrueAlert Device Reports Reference
