579-1034
Rev. F
Appliance specifications
Environmental specifications:
Rated voltage range
Special application
17 - 31 VRMS
Temperature range 32° F to 120° F (0° C to 49° C)
Humidity range 10% to 93%, non-condensing at 104° F (40° C)
Connections
Terminal for 18 AWG to 12 AWG
(0.82 mm
2
to 3.31 mm
2
)
Sound pressure level measurement (dBA)
Reverberant Room at 10
Feet in accordance with
UL464 (See Note 2)
Voltage
(Vrms)
Horn mode
steady
Horn mode
coded
(See Note 1)
High volume
setting using addressable
controller (See Note 3)
17 (Min.) 87.6 83.1
23 89.8 86
31 (Max.) 91.9 86
Low volume setting using
addressable controller
(See Note 3)
17 (Min.) 80.6 76.9
23 83.4 79.2
31 (Max.) 86.2 82.3
Anechoic Room at 10 feet in accordance with ULC S525, see note 4.
High volume setting 17 (Min.) 89.9 89.6
23 92.5 92.4
31 (Max.) 94.4 93.9
Low volume setting 17 (Min.) 84.1 83.6
23 86.7 86.6
31 (Max.) 89.1 88.6
Notes:
1. The coded category covers both Temporal and March time cadences.
2. Reverberant
dBA measurements are a minimum UL rating based on sound
power level measurements made in UL’s reverberant test chamber.
3. High and low volume settings are configured with DIP switch (CFIG1) on the
controller.
4. If you install the 4905-9838 Sound Damper, the anechoic measurements
decrease by approximately 9 dBA.
Current draw
Application Appliance
type
Maximum RMS
operating current
UL464/
ULCS525
(0° C TO 50° C)
AO 23 mA
ULC directional characteristics for horn
Access
Angle
dBA
Horizontal 61.5° left and right -3 dBA
90° left and right -4.6
dBA
Vertical 62° up and down -3 dBA
90° up and down -3.8
dBA
CAUTION:
• The appliances are available in red and white. Do
not paint or otherwise alter the factory finishes in
any way.
• Anechoic dBA levels below 85 do not meet ULC
requirements for public notification.
