Simpli Home ARTISAN - Top Panel and Back Panel Installation

/1813
STEP-8
ASSEMBLY
MODEL # AXCART21-WH
1. Align Wood Dowels with guide
holes on Top Shelf D and attach
Top Dividers C2 to Top Shelf D .
STEP-9
1. Attach twelve Cam Lock Pins 2 into pre-drilled holes on Top A .
2. Use Phillips screwdriver to secure Cam Lock Pins. Do not over-tighten.
P
X
A
2
Front /
Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
BR
BL
E
C2
C2
E
BR
BL
C2
C2
D
D
