Simpli Home ARTISAN - Page 14

/1814
STEP-10
ASSEMBLY
MODEL # AXCART21-WH
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front /
Avant
Front /
Avant
Front /
Avant
2. Insert
three
Cam Locks 2 into guide holes on
each part BL , BR , C2 .
3.
Use Phillips screwdriver to secure Cam Locks. Do not over-tighten
1. Align Cam Lock Pin with guide holes on
parts BL , BR , C2 and attach Top A to parts BL , BR , C2 .
2
A
A
A
