Simpli Home LOWRY - Step 3: Prepare Side Panels; Step 4: Attach Left Side Panel

ASSEMBLY MODEL # AXCLRY-08RNAB
/2110
STEP-3
C L C R
&
11
C
L
C R
1. Insert two Dowels 11 into drilled holes on each Left Side CL and Right Side CR .
2. Use rubber mallet to tap Dowels 11 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
11
STEP-4
1. Attach Bottom Shelf B to Left Side CL using three Allen Key Screws 4 .
2. Use Allen Key 5 to tighten screws. Do not over-tighten.
B
C L
4
5
4
Front /
Avant
Front /
Avant
Front /
Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
