Simpli Home LOWRY - Pre-Assembly Information; Part Identification

/215
PART DESCRIPTION
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
PRE-ASSEMBLY INFORMATION MODEL # AXCLRY-08RNAB
.
A
.
B
.
E
TOP
QTY 1
BOTTOM SHELF
QTY 1
LEFT SIDE
QTY 1
.
L
C
RIGHT SIDE
QTY 1
.
RC
.
LD
.
RD
LEFT DIVIDER
QTY 1
RIGHT DIVIDER
QTY 1
.
F
.
G
DOOR (L&R Same)
QTY 2
SIDE SHELF
QTY 2
BACK PANEL
QTY 1
.
I
.
H
MIDDLE SHELF
QTY 1
LEG
QTY 2
Warning Label
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
