ASSEMBLY MODEL # AXCLRY-08RNAB
/2116
STEP-10
D
R
D
L
C
L
12
10
C
R
E
E
E
E
C
R
C
L
D
L
D
R
1. Attach Adjustable Hinges 12 on Doors E to Sides CL , CR using Phillips
Screws 10 into guide holes on Sides CL , CR .
2. Attach Magnets 7 using Phillips Screws 9 into guide holes on Left Divider DL and
Right Divider DR .
3. Use Phillips screwdriver to snugly tighten screw.
7
9
79
To Next Page
