5. Reinstall the pulley in lower tab as shown in figure 4
using the 2-1 /4 inch long capscrew (A) and the belt
stop (F) supplied with the hitch. Slip the belt between
pulley and belt stop before tightening (flat side of belt
goes against pulley).
6. Push the belt tensioning lever down and forward.
Install the belt on the pulleys as shown in figure 5. Be
sure to install belt in inner groove of PTO pulley.
There must be no twists in the belt.
7. Pull the belt tensioning lever back and up. Make sure
there is clearance between the belt stops (D, E & H,
figure 5) and the belt.
8. Insert end of lift rod through hole in tractor lift arm
(A, figure 6). Install the spring clip (B) through hole
in lift rod (C).
9. If installing for the first time, perform initial
adjustment as follows:
a. Fully lower the lift lever. Place the front set collar
one inch from the rod guide as shown in figure 7,
and tighten the setscrew.
b. Place rear set collar against the spring, compress
the spring slightly, and tighten the setscrew. (The
more the spring is compressed, the more down
pressure there will be.)
MOUNTED
ON HITCH
FLAT SIDE
OF BELT
INSTALL BELT IN
INNER GROOVE.
INSTALL IN
LOWER TAB
(§) "V" SIDE
OF BELT
£>
INSIDE
SNOWTHROWER
Figure 5. Belt Diagram
A. PTO Pulley
B. Rear Idler Pulley
C. Snowthrower Pulley
D. Belt Stop
o
FRONT
VIEWED FROM
LEFT SIDE
E. Belt Stop
F. Idler Pulley
G. Front Idler Pulley
H. Belt Stop
Figure 6. Attach Lift Rod
A. Tractor Lift Arm
B. Spring Clip D. Rear Set Collar
C- Lift Rod E. Spring
Figure 7. Lift Rod Adjustment
A. Front Set Collar D. Rear Set Collar
B. Rod Guide E. Lift Rod
C. Spring
