Installation & Removal
INSTALLATION
1. The snowthrower hitch must be installed on front
axle as shown in figure 2. To do this, first insert the
hitch arms in tractor hitch as shown in figure 2. To
align the holes, push the snowthrower hitch onto the
front axle so it hooks firmly on top of axle as shown
in figure 1. Insert the two pins (C, figure 2) to secure
the hitch and install the two spring clips (D).
Position the snowthrower in front of the tractor.
Lift up the snowthrower and align with hitch (C) as
shown in figure 3. On each side, insert pin (A) thru
the clip (B), hitch, and snowthrower. Install spring
clips in the two pins.
Figure 1. Install Hitch
A. Hitch hooked on top of axle. C. Flat Idler Pulley
B. Fro*'* Axle D. Belt Stop
Figure 3. Attach Snowthrower to Hitch
A. Pin C. Hitch
B. Clip D. Snowthrower
4. Go around to the left side of the tractor. Remove the
front idler pulley (D, figure 4) by removing the
capscrew and attaching hardware. Store the
capscrew; it will not be used with snowthrower.
Figure 2. Install Hitch
A. Snowthrower Hitch Arm (right side) C. Pin
B. Tractor Hitch D. Spring Clip
Figure 4. Idler Pulley & Belt Stop (on tractor)
A. Capscrew, 3/8 x 2-1/4
B. Spacer
C. Washer
D. Idler Pullev
4
