3 - 9
3 Maintenance
Lubrication
*2388B
Figure 10. Brake Pedal Pivot Point
Figure 14. Front Axle Lubrication Points
Figure 13. Rider Lubrication Points - Rear Half (Gear
Model Shown)
Figure 11. Rider Lubrication Points - Front Half
*2402
*2390
NOTES:
1. Unless specified, use torque specifications shown on standard hardware torque specification chart.
2. Grease locations indicated by grease gun symbol:
3. Oil locations indicated by oil can symbol:
*2397
Figure 12. Mower Deck Lubrication Points
Figure 15. Arbor Lubrication Points
Note: On 30” mower,
grease fitting is on
topside of deck.
