Simplicity 1692380 Service & Repair Manual

8 - 3
8 Hand Controls Repair
Hand Controls Assembly
1 1 WASHER, Plain
2 2 BUSHING
3 1 PIN
4 1 SPACER
5 1 TUBE, Steering
6 3 SPACER, 17/64 x 3/8 x 21/64
7 1 STEERING WHEEL ASSY.
(Incl. Ref. Nos. 26 & 50)
8 1 PLATE, Steering Mounting
9 2 BUSHING
10 1 SHAFT ASSY., Steering
11 1 ROD, Parking Brake
12 1 ROD, Shift
13 1 SPRING, Torsion
14 1 SHROUD, Front
15 1 GEAR, Steering
16 1 QUADRANT, Lift
17 1 ROD, Lift Height
18 1 SUPPORT, Steering
19 2 CLAMP
20 1 TUBE ASSY., Shift
21 1 KNOB, Rod, Shift
22 1 KNOB, Rod, Parking Brake
23 1 KNOB, Rod, Lift Height
24 1 DASH, Hydro
25 1 DASH, Gear
26 1 CAP, Steering Wheel
27 2 NUT, Hex, Jam, 1/4-20
28 2 COTTER PIN
29 1 CAPSCREW, Hex Hd., 5/16-18 x 1-1/2
30 2 WASHER, Plain, 1/4
31 1 CAPSCREW, Hex Hd., 3/8-16 x 2
32 2 CAPSCREW, Hex, 1/4-20 x 7/8
33 2 WASHER, Plain, 13/32 x 1-1/2 x 1/8
34 1 WASHER, 13/32 x 1-1/2 x 1/8
35 1 WASHER, Plain, 17/32 x 1-1/4 x 7/64
36 3 SCREW, Hex, Flange, Taptite, 1/4-20 x 1/2
37 3 SCREW, Hex, Flange, Taptite, 1/4-20 x 3/4
38 2 NUT, Hex, 3/8-16
39 4 SCREW, Hex, Whizlock, 5/16-18 x 3/4
40 2 NUT, Hex, Flange, Whizlock, 1/4-20
41 1 NUT, Hex, Flange, 1/4-20
42 2 NUT, Hex, Flange, Whizlock, 5/16-18
43 2 CARRIAGE BOLT, 3/8-16 x 1
44 2 PUSH NUT, 5/16
45 4 PAL NUT, 5/16-18
46 1 WASHER, Plain, 11/32 x 1 x 1/8
47 3 WASHER, Plain, 49/64 x 1-1/16 x 5/64
48 1 WASHER, Plain
49 1 NUT, Hex, Flange Lock, 3/8-16
50 1 ROLL PIN, 5/16 x 2
Ref. Qty. Description Ref. Qty. Description
Front Column and Dash
