Simplicity 1692380 User Manual

33
Specifications
Seat Molded Type with Foam Cushion and Spring
Construction
Front Wheels Tire Size 13 x 5.00-6
Pneumatic Inflation Pressure 10 -12 psi
(68 - 82 kPa)
Rear Wheels Tire Size 16 x 6.50-8
Pneumatic Inflation Pressure 10 -12 psi
(82 - 103 kPa)
Accessibility Seat Deck Tips Forward
Seat Type Bucket, High Back, Adjustable w/
Spring Suspension, Fore and Aft Adjustable
Fuel Tank Material: Non-Corrosive Polyethylene Alloy
Capacity: 2 Gallons (7.5 L)
Turning Radius Inside Rear Tire 12 In. (30.2 cm)
DIMENSIONS
Rider
Overall Length 61 In. (155 cm)
Overall Width
- w/30 mower 38.5 In. (97.8 cm)
- w/34 mower 45.5 In. (115.6 cm)
- at rear wheels 33 In. (83.8 cm)
Height at
- steering wheel 41 In. (104.1 cm)
- seat back 35 In. (88.9 cm)
- engine cover 28 In. (71.1 cm)
Wheel Base 43 In. (109.2 cm)
Weight (approx.)
- 8.5 HP w/30”mower Net: 405 lbs. (183 kg)
Shipping: 530 Ibs. (241 kg)
- 12 HP w/30”mower Net: 405 lbs. (183 kg)
Shipping: 530 Ibs. (241 kg)
- 12 HP w/34”mower Net: 405 lbs. (183 kg)
Shipping: 530 Ibs. (241 kg)
- 13 HP w/34”mower Net: 405 lbs. (183 kg)
Shipping: 530 Ibs. (241 kg)
Mower
Type: 30” Single Blade
34” Dual Blade
Height of Cut 1.0 - 3.75 In. (2.45- 9.53 cm)
Cutting Positions Infinite
Level Adjustments Side-to-Side & Front-to-Back
Spindles Sealed Ball Bearings w/Lube Fitting
Blade Mounting Center Bolt With Spring Positioning
Discharge Deflector Hinged with Spring Positioning
Mounting At Front Axle - Quick Hitch
with Auto-Leveler
TM
