Simplicity 1694286 User Manual

6
Installation Instructions Sub-Frame Hitch
Figure 8. Install Hitch
A. J-Hooks C. Hook
B. Hitch Rod D. Clamp Plate
A
B
C
D
Install Hitch
1. Slide the hitch under the tractor.
2. Raise the rear of the hitch and place the hook (C,
Figure 8) over the lift shaft.
3. Connect the front of the hitch to the tractor J-hooks
(A) using the hitch rod (B) and a safety clip.
4. Push the clamp plate (D) backwards until the hook
(C) is snug against the lift shaft. Tighten the clamp
plate hardware.

Simplicity 1694286 Specifications

General

Brand	Simplicity
Model	1694286
Category	Automobile Accessories
Language	English
