PART NO. DESCRIPTIONREF NO QTY.
Auger Housing Group
Footnotes
AUGER HOUSING ASSEMBLY, 24" 0010 1737694C 1
AUGER HOUSING ASSEMBLY, 28" 0010 1737696C 1
AUGER HOUSING ASSEMBLY, 32" 0010 1737698C 1
AUGER HOUSING ASSEMBLY, 38" 0010 1737700C 1
DRIFT CUTTER 0020 1733102BM 2
NUT, Wing, Serrated, 5/16-18 0030 720125 2
BOLT, Carriage, 5/16-18 x 3/4 0040 723873 2
NUT, Retainer, 5/16-18 0050 1930659 3
BLADE, Scraper, 24" 0060 1709946A 1
BLADE, Scraper, 28" 0060 1709947A 1
BLADE, Scraper, 32" 0060 1709948A 1
BLADE, Scraper, 38" 0060 1723921A 1
BOLT, Carriage, 5/16-18 x 3/4, G5 0070 723873 5
NUT, Hex Flange, Two Way Lock, 5/16-18 0080 1935048 5
BOLT, Carriage, 3/8-16 x 3/4, G5 (24", 28" & 32" Housing Only) 0090 1960711 4
BOLT, Carriage, 3/8-16 x 1, G5 (38" Housing Only) 0090 1960702 4
SHOE, Skid, Reversible (24", 28" & 32" Housing Only) 0100 1727854BM 2
SHOE, Skid (38" Housing Only) 0100 1725747BM 2
NUT, Hex Flange, ESNA, 3/8-16 0110 1960687 4
BEARING, Ball 0120 1734645 2
CAPSCREW, Hex Washer Head, Taptite, 5/16-18 x 3/4 0130 1664847 6
NUT, Nylock, 10 x 24 0140 722401 2
CLAMP, Retainer 0150 1736620 2
SCREW, Truss Head Torx, #10-24 x 3/8 0160 1960569 2
BRUSH, Cleanout 0170 1736094 1
BEARING, Ball 0180 2108202 1
RETAINER, Ball Bearing 0190 1665982 1
CAPSCREW, Hex Flange, Whiz Lock, 5/16-18 x 3/4 0200 1960738 3
The above parts group applies to the following Mfg. Nos.:
15
2010
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1695824 - P1524E
1695825 - (P1728E)
1695826 - (P1732E)
1695827 - (P1738E)
1695846 - P1732EX
1695903 - (P1728EX)
1751687
