PART NO. DESCRIPTIONREF NO QTY.
Traction Drive Group
Footnotes
BUSHING, 1 Long 0010 1666001 1
AXLE, 22-13/16 Long 0020 1736641 1
ARM & PIVOT ASSEMBLY 0030 1670849 1
BEARING 0030-10 1665521 1
BUSHING, Flange 0030-20 1666425 2
BUSHING 0030-30 1666855 1
SCREW, Set, 5/16-18 x 1/2, G8 0040 1928721 2
PULLEY ASSEMBLY 0050 1672595 1
SPRING, Extension, 1/2 OD 0060 1725666 1
WASHER, 1-1/32 X 1-5/8 OD 0070 1919394 1
COLLAR, Set, 1/4 X 1-1/4 x 1/2 0080 1729254 1
NUT, Hex-Flange, 5/16-18 0090 1960686 1
GEAR ASSEMBLY 0100 1736639 1
WASHER, 3/4 0110 1960114 3
GEAR & HUB ASSEMBLY 0120 1730228 1
WASHER, 3/16 0130 2860169 1
BUSHING, 5/32 0140 1720305 1
Fitting, Lube, Straight, 1/4-28 0150 7076998 1
CAPSCREW, Hex-Head, 1/4-20 x 1-1/2 0160 51374 2
PIN, Quick, 1-3/16 Lg 0170 1722460 1
ROD, 9-1/2 Lg 0180 1726467 1
WASHER, 5/8 0190 1924366 1
KEY, Woodruff, 3/16 x 5/8, #61 0200 2818312 1
DISC, Drive, w/ Spindle 0210 1719879 1
WASHER, 5/8 0220 2860164 4
JACKSHAFT 0230 1718752 1
SPRING, Compression 0240 1720298 1
CLUTCH, Sliding, 1-1/2 OD 0250 1718689 1
ARM, Clutch 0260 1720078A 1
RING, Retaining, # 74, 3/4 Dia. 0270 2827732 1
GEAR, Stationary Clut 0280 1718688 1
SPACER, 1 Lg 0290 1679556 1
SPROCKET 0300 1667330 1
GEAR, 10T 0310 1718687 1
CAPSCREW, Hex-Head, 5/16-18 x 1, G5 0320 1921333 3
NUT, Hex, Conical Washer, 5/16-18 0330 1960684 6
RETAINER, Bearing 0340 1667341 4
BEARING, Ball, 11/16 X 1-9/16 x 15/32 0350 1705897 4
SCREW, Hex Washer-Head, 5/16-18 x 5/8 0360 1930601 8
SPROCKET, 10T 0370 1726931 1
COLLAR, 1-1/4 x 2 x 1/2 0380 1667335 1
SCREW, Set, 1/4-20 x 1/2 0390 1724333 2
COLLAR, Thrust, 1-1/4 ID x 2 OD 0400 1678956 2
PIN, LOOP 3/8 Dia. x 2-3/32 Lg 0410 1666207 1
The above parts group applies to the following Mfg. Nos.:
17
2010
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1695824 - P1524E
1695825 - (P1728E)
1695826 - (P1732E)
1695827 - (P1738E)
1695846 - P1732EX
1695903 - (P1728EX)
