PART NO. DESCRIPTIONREF NO QTY.
Chute & Rotation Group - Electric Chute/Remote Deflector
Footnotes
PINION, 1-1/4 Lg 0010 1728967 1
NUT, Whiz Lock, #10-24 0020 1960745 3
CAPSCREW, Hex Washer, #10 x 1-1/4, G2 0030 2860604 3
CAPSCREW, Hex Washer, Self Tapping, 1/4-20 x 3/8 0040 1927428 1
COVER, Gear 0050 1733934A 1
RETAINER, Chute 0060 1666613 3
CAPSCREW, Hex Washer, 10-14 x 5/8 0070 1960001 3
SPRING, Compression, 9/16 OD x 6-1/16 Lg 0080 1734647 1
SWITCH, Rocker, Chute Rotation, 5-Pin 0090 1728969 1
CABLE, Deflector Control 0100 1732971 1
PUSHNUT, 5/16 Dia. x 5/8 OD 0110 1932718 1
SPACER, 1/2 OD x 7/32 Lg 0120 1666697 2
ROD, 5/16 Dia., 5-7/8 Lg 0130 1734708A 1
TIE, Self Locking, 7-5/16 Lg 0140 1701011 1
DECAL, Hinge (24", 28" & 32" Models Only) 0150 1706085 2
DECAL, Hinge (38" Models Only) 0150 1733598 2
CHUTE ASSEMBLY, 32" (24", 28" & 32" Models Only) 0160 1734400C 1
CHUTE ASSEMBLY, 38" (38" Models Only) 0160 1736419C 1
NUT, Hex Flange, 5/16-18 0170 1960686 1
WASHER, Nylon, 3/8 0180 2860210 1
BOLT, Carriage, 5/16-18 x 3/4, G5 0190 1931333 1
MOTOR, Spout Rotator, 38" 0200 1728965 1
PUSHNUT, 1/4 Dia. (CE/Export Only) 0210 1960126 2
GUARD & SUPPORT ASSEMBLY (CE/Export Only) 0220 1735174 1
The above parts group applies to the following Mfg. Nos.:
25
2010
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1695824 - P1524E
1695825 - (P1728E)
1695826 - (P1732E)
1695827 - (P1738E)
1695846 - P1732EX
1695903 - (P1728EX)
1751687
