PART NO. DESCRIPTIONREF NO QTY.
Handles & Controls Group
Footnotes
TIE, Self Lock 0010 1701011 5
HARNESS, Wiring 0020 1728968 1
CABLE & SPRING ASSEMBLY, Auger, R.H. 0030 1735148 1
CABLE & SPRING ASSEMBLY, Traction, L.H. 0040 1728115 1
CAPSCREW, Hex Flange, 5/16-18 x 3/4 0050 1664847 6
HANDLE ASSEMBLY 0060 1733890C 1
CLIP, Wire 0070 2834683 2
GROMMET 0080 1664022 1
LEVER, Clutch, L.H 0090 1725205A 1
LEVER, Clutch, R.H. 0093 1735133A 1
BUSHING 0100 1732732 3
CAPSCREW, Hex Washer Head, Taptite, #12-24 x 1 0110 1960471 4
HANDLE, Clutch, L.H. 0120 1727127 1
ROD, Control, 2-7/8 0130 1677453 1
SCREW, Pan Head Torx, #10 x 1/2 0140 1725702 1
CABLE & HANDLE ASSEMBLY 0150 1718791 1
GRIP, Hand, Heated 0160 1723965 2
NUT, Hex Flange, Whiz Lock, 1/4-20 0170 1930641 4
CAPSCREW, Hex Flange Head, 1/4-20 x 3/4 0180 1935450 4
CAPSCREW, Hex Washer Head, Taptite, 1/4-20 x 3/4 0190 1925592 6
DASH, Handle 0200 1734387C 1
NUT, Hex Flange, ESNA, 5/16-18 0210 1960686 1
SPRING, Compression 0220 1701342 1
LATCH, Control 0230 1705898 1
SPACER 0240 1678579 1
CAPSCREW, Hex Flange, Whiz Lock, 5/16-18 x 1-1/2 0250 1933689 1
RESISTOR BLOCK 0260 1724037 1
GUIDE, Control 0270 1705899 1
SCREW, Hex Washer Head, Taptite, #10-24 x 1 0280 1928732 1
HANDLE, Clutch, R.H. 0290 1727128 1
CAPSCREW, Hex Flange Head, 1/4-20 x 3/4 0300 1923341 1
BRACKET, Shift Control 0310 1723935 1
SWITCH, Hand Warmer 0320 1723967 1
NUT, Hex Keps, 1/4-20 0330 1960685 4
ROD & CLEVIS ASSEMBLY 0340 1668523 1
CAPSCREW, Hex Flange, Whiz Lock, 1/4-20 x 2-1/4 0350 1960705 1
KNOB 0360 1732470 2
BOLT, Carriage, 1/4-20 x 3/4 0370 1931317 2
ROD, Shift, Upper, 10-1/2 0380 1734388 1
ROD, Shift, 15-5/16 0390 1666255 1
PIN, Quick 0400 1722460 1
WASHER, 1/2 0410 1924361 1
BLOCK, Pivot 0420 1668524 2
WASHER, Curved 0430 1668681 1
Note* See your local hardware store for replacement bulbs.
The above parts group applies to the following Mfg. Nos.:
5
2010
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1695824 - P1524E
1695825 - (P1728E)
1695826 - (P1732E)
1695827 - (P1738E)
1695846 - P1732EX
1695903 - (P1728EX)
1751687
