PART NO. DESCRIPTIONREF NO QTY.
Handles & Controls Group
Footnotes
PIVOT ASSEMBLY 0440 1734696 1
ROD, Chute, Deflector 0460 1735290 1
BRACKET, Deflector Handle 0470 1734385A 1
CAPSCREW, Hex Flange Head, 1/4-20 x 2 0480 1921963 1
NUT, Hex Flange, ESNA, 1/4-20 0490 1960694 1
SPRING, Compression 0500 1734709 1
CLIP, Hair Pin 0510 1960074 1
BUSHING, 1/2 ID x 3/4 OD x 1/4 0530 1668185 2
HEADLIGHT ASSEMBLY 0550 1737965 1
* BULB, Headlight, Halogen, 881-12V 27W (Included with Ref. No. 0550) 0550-10 ----- 1
WASHER, 1/4 0560 1921319 2
SPACER, 5/16 ID x 1/2 OD x 1/4 0570 1666697 1
Note* See your local hardware store for replacement bulbs.
The above parts group applies to the following Mfg. Nos.:
7
2010
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1695824 - P1524E
1695825 - (P1728E)
1695826 - (P1732E)
1695827 - (P1738E)
1695846 - P1732EX
1695903 - (P1728EX)
1751687
