PART NO. DESCRIPTIONREF NO QTY.
Engine & Frame Group
Footnotes
* ENGINE, 14.5TP Briggs & Stratton (Domestic) (Engine Model: 21M314-0119-E1) 0010 21M314-0130-E1 1
* ENGINE, 16.5TP Briggs & Stratton (Domestic) (Engine Model: 21M314-0119-E1) 0010 21M314-0119-E1 1
* ENGINE, 16.5TP Briggs & Stratton (CE/Export) (Engine Model: 21M314-0122-E1) 0010 21M314-0122-E1 1
GUARD, Muffler, Plate (Domestic) 0010-10 797095 1
GUARD, Muffler, Cage (Export) 0010-10 796384 1
CAPSCREW, Hex Washer Head, Muffler Guard 0010-20 699234 3
CAP, Fuel 0010-30 795027 1
CAPSCREW, Hex Head, 5/16-18 x 1-1/2 0030 1921221 3
NUT, Hex Flange, Whiz Lock, 5/16-18 0060 2831277 5
CAPSCREW, Hex Head, 5/16-18 x 1-3/4, G5 0070 2822127 1
PULLEY, Drive 0100 1726864 1
PULLEY, Engine 0130 1726863 1
WICK, Oil 0140 1685366 1
PULLEY HALF, Inside 0150 1726868 1
PULLEY, Engine 0155 1726869 1
WASHER, Thrust 0160 1701818 1
CAPSCREW, Hex Head, 3/8-24 x 1-1/2 0180 1922128 1
WASHER, 3/8 0190 1922755 1
LOCKWASHER, Spring 0200 1916965 1
SPRING, Compression 0230 1701849 1
SPRING, Compression 0240 1702425 1
STOP, Belt 0290 1731178 2
CAPSCREW, Hex Head, 5/16-24 x 3/4 0300 1921515 2
LOCKWASHER, Spring 0320 1917356 2
V-BELT, Auger, HA, 41.78 0340 1732249 1
V-BELT, Drive, 3L, 31.0 0350 1672732 1
PULLEY, Idler 0360 1726348 1
CAPSCREW, Hex Flange, Whiz Lock, 3/8-16 x 1-3/4 0380 2860709 1
NUT, Hex Flange, Whiz Lock, 3/8-16 0400 1928352 1
PULLEY, Idler 0420 1668477 1
CAPSCREW, Hex Head, 3/8-16 x 1-1/2 0430 1960647 1
NUT, Center Lock, 5/16-18 0460 7091575 2
WASHER, 5/16 0470 1919326 6
SPRING, Extension 0490 2159106 1
ARM, Idler 0510 1703046A 1
PIN, Flat Head Drilled, 1-3/4 0520 1665994 1
PIN, Quick 0530 1722460 2
SPRING, Extension 0540 1727149 1
CAPSCREW, Hex Flange, Whiz Lock, 5/16-18 x 3/4 0560 1930591 3
CAPSCREW, Hex Flange, Whiz Lock, 5/16-18 x 1-1/4 0570 1930595 2
NUT, Hex Flange, Whiz Lock, 5/16-18 0580 1927557 4
COVER, Bottom 0600 1726870C 1
CAPSCREW, Hex Washer Head, Taptite, 1/4-20 x 1/2 0610 1925003 2
COVER, Belt 0630 1725287 1
Note: * See your local Briggs & Stratton distributor for parts & service.
The above parts group applies to the following Mfg. Nos.:
9
2010
Milwaukee, WI, USA. All rights reserved
© Copyright by Briggs & Stratton Corporation
1695824 - P1524E
1695825 - (P1728E)
1695826 - (P1732E)
1695827 - (P1738E)
1695846 - P1732EX
1695903 - (P1728EX)
