Not for
Reproduction
28
Figure 16
AB
8. Place mower in the lowest cutting position, then
disconnect the mower wire harness (A, Figure 17) from
the tractor wire harness (B).
9. Turn wheels straight.
10. Pull back on spring-loaded lever (A, Figure 18) and lift
mower hitch o of the tractor hitch brackets.
11. Turn wheels fully left, and slide mower deck out from
under the right side of the tractor.
+
6
5
4
3
2
1
Figure 17
A
B
Figure 18
A
