17
INSTALLATION
Figure 22. Install the Bags
A. Bags
B. Back Plate
A
B
Figure 24. Install Hinge Pins
A. Cover
B. Hinge Pin
C. Hinge
D. Hair Pin Clip
A
B
C
D
Figure 23. Install Cover
A. Cover
B. Bags
C. Hinges
A
C
B
Install Cover
1. See Figure 22. Hook the bags (A) on the back
plate (B). Note: If desired, the bags can be lined
with 30 gallon trash bags for easy disposal.
2. See Figure 23. Set the cover (A) on top of the
bags (B) and align the hinges (C).
3. See Figure 24. Install the hinge pins (B) through
the hinges (C) and secure with a hair pin clip (D).
NOTE: Push the hair pin clip all the way on or it will
be bent by the hinge when the cover is opened.
4. Secure the cover by connecting the rubber strap
to the cover latch.
