B-5
“Catcher full” alarm
The “catcher full” alarm sounds when the grass catcher has
been filled with cut grass. When the alarm sounds, push the
PTO switch (B) down to disengage the mower blades. Travel to
the area in which you desire to dump the grass, then empty the
catcher.
Catcher open
The catcher open pedal (A) unlocks the catcher so that it may
be emptied. To empty the catcher, depress the pedal (A) and
pull forward on the handle (C) until the catcher opens fully.
Catcher close
Push the handle (C) firmly down until the catcher latches closed.
A
C
B

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Simplicity Baron and is the answer not in the manual?

Simplicity Baron Specifications

General IconGeneral
Fuel TypeGasoline
TransmissionHydrostatic
Cutting Width42 inches
Turning Radius18 inches
EngineBriggs & Stratton
