5.
Mount
"V"
belt
in
place
on
driven
pulley
as
shown
in
figure
5
and
attach
spring
to
bottom
hole
in
the
spring
holder
and
hook
other
end
of
the
spring
to
the
idler
lever
spring
holder.
Mount
belt
stop
as
shown
with
3/8"
bolt,
flat
washer,
lockwasher
and
hex
nut.
When
idler
pulley
is
engaged,
1/8"
clearance
between
belt
stop
and
back
of
"V"
belt
is
required.
Note:
"V"
belt
runs
under
idler
pulley.
See
figure
5.
LUBRICATION
The
power
take-off
is
lubricated
by
means
of
one
grease
fitting
located
on
the
bottom
front
of
the
drive
bracket
assembly.
Occasionally
apply
grease
by
means
of
a
standard
grease
gun
loaded
with
auto¬
motive
type
grease.
Be
sure
to
wipe
dirt
and
grit
from
grease
fitting
before
applying
grease
gun.
Lu¬
bricate
all
pivot
points
and
idler
pulley
bearings
with
SAE
20
oil
every
few
hours
of
operation.
OPERATION
Operation
of
the
power
take-off
is
controlled
by
movement
of
the
clutch
lever
assembly.
See
figure
4.
When
the
clutch
lever
is
in
the
forward
raised
position,
the
clutch
rod
releases
the
tension
holding
the
idler
pulley
against
the
drive
belt,
and
power
will
not
be
transmitted
to
the
driven
pulley
of
the
power
take-off
assembly.
When
the
clutch
lever
is
in
the
back,
depressed
position,
the
clutch
rod
applies
tension
to
the
idler
pulley
and
as
the
idler
pulley
takes-up
the
slack
in
the
drive
belt,
power
is
trans¬
mitted
from
the
drive
pulley
on
bevel
gear
box
shaft
to
the
driven
pulley
of
the
power
take-off.
Figure
4
shows
clutch
lever
in
drive
position.
ADJUSTMENT
At
points
"A”
and
"B”
of
figure
4,
check
tightness
of
hex
nut
to
be
sure
that
clutch
lever
assembly
and
clutch
rod
are
free
to
pivot
without
binding.
Place
clutch
lever
in
"drive"
position
and
observe
clearance
between
collar
"C"
(figure
4)
and
end
of
bracket.
This
clearance
should
normally
be
ap¬
proximately
3/4
inch;
at
this
setting
the
idler
pulley
should
be
snugly
against
the
drive
belt.
If
additional
tension
is
required,
release
clutch
lever
and
loosen
set
screw
on
collar
and
slide
collar
farther
back
on
clutch
rod.
Retighten
set
screw
in
collar
and
put
clutch
lever
in
drive
position.
Recheck
clearance.
The
tension
of
the
idler
pulley
against
the
drive
belt
must
be
sufficient
to
operate
whichever
tractor
at¬
tachment
is
being
used.
Any
additional
tension
is
unnecessary'
and
will
only
cause
premature
failure
of
belts
and
idler
pulley
bearings.
