Simplicity SA2200 User Manual

5
FRONT VIEW
O
1 FACE COVER
Opens to provide access to the light bulb and the
presser foot pressure regulator.
O
2 REVERSE LEVER
Press this lever down and hold in place to sew in
reverse.
O
3 BOBBIN WINDING TENSION DISC
Used to wind a bobbin when threading the
machine.
O
4 THREAD TENSION DIAL
Controls the upper thread for proper stitch formation.
O
5 STITCH WIDTH DIAL
Sets the width of a stitch.
O
6 STITCH SELECTOR DIAL
Turn the dial in either direction to select a stitch.
O
7 STITCH SELECTOR WINDOW
The letter of the selected stitch appears in this
window.
O
8 BOBBIN WINDER SPINDLE
Winds thread on a bobbin for lower threading.
O
9 HAND WHEEL
Turn the hand wheel toward you to raise the
needle up and down.
O
10 STITCH LENGTH DIAL
Sets the length of the stitch.
O
11 FREE-ARM COVER
Provides a flat surface for most sewing. Remove
it to convert to free-arm sewing.
O
12 NEEDLE PLATE
Supports the fabric while sewing. Has seam guide
markings on right side.
O
13 FEED TEETH
The metal teeth under the needle plate that push
or feed the fabric through the machine.
O
14 PRESSER FOOT
Holds the fabric firmly against the feed teeth for
proper stitch formation.
O
15 PRESSER FOOT HOLDER
Holds the snap-on presser foot in sewing position.
The presser foot holder is removed when using
screw-on feet.
O
16 PRESSER FOOT THUMB SCREW
Secures the presser foot or presser foot holder to
the presser foot bar.
O
17 BUILT-IN NEEDLE THREADER
Threads the eye of the needle, front to back.
O
18 BUTTONHOLE LEVER
Pull this lever down when using the one-step
buttonhole foot.
O
19 NEEDLE CLAMP SCREW
Loosen to remove a needle; tighten to secure a
needle in position.
BACK VIEW
O
20 CARRY HANDLE
Simply lift to carry the Simplicity sewing
machine from one place to another.
O
21 PRESSER FOOT LEVER
Lift to r
aise the presser foot and release the thread
tension; lower to lower the presser foot and engage
the thread tension.
O
22
THREAD CUTTER ON NEEDLE BAR
Use to cut threads after completing a seam.
O
23 POWER CORD RECEPTACLE
Connect the three-prong power plug here.
O
24 MAIN SWITCH
Turns the main power and built-in sewing light
on or off.
O
25 STRETCH STITCH ADJUSTMENT SCREW
Adjust this screw if stretch stitches (color-coded
red) are not forming properly.
O
26 RETRACTABLE SPOOL PINS
Raise the spool pin to hold the spools of thread.
KNOW YOUR SIMPLICITY SEWING MACHINE
