Simplicity SMF2 Instruction Manual

6903-002002 <05>
11
[03]
[01, 04]
[03]
[03]
[T]
[T]
[06]
[22]
3 Attach your TV to the Arm
1
2
3-1 Position arm
3-2 Attach TV
HEAVY! You will need assistance with this step.
1. Attach the TV bracket [01, 04 ] to the arm assembly [03].
2. Install and tighten locking screw [06] using the 5/32 in.
allen key [22].
Position arm [03] so the elbow is pressed against the wall.
Tighten the tension adjustment [T] to prevent the arms from
moving while installing the TV bracket.
