Simplicity SMF2 Instruction Manual

6903-002002 <05>
5
B
400 mm
(16 in.)
A
[04]
[02]
[02]
[01]
Before You Begin
Determine which interface to use
Select a TV interface based on the particular hole pattern of your TV. DO NOT begin installation yet, only determine which interface to
use.
A. Use the smaller interface [04] for 75 - 200 mm hole patterns.
B. Use the larger interface [01, 02, 05] for hole patterns between 200 and 400 mm, and up to 450 mm wide.
200 - 450 mm
(8 - 18 in.)
75 - 200 mm
(3 - 8 in.)
75 - 200 mm
(3 - 8 in.)
400 mm
(16 in.)
200 - 450 mm
(8 - 18 in.)
OR
75 - 200 mm
(3 - 8 in.)
75 - 200 mm
(3 - 8 in.)
[05]
