42” Snow Plow/Dozer Blade
ASSEMBLY
1.
Place the blade on a flat surface.
2. install two bar stops (A, figure 2) using the two
5/l 6-l 8 x
1”
taptite’screws (B).
Figure 2. Bar Stop
A. Bar Stop
B. Taptite Screw,
5/l
6-l 8
x
1
3:
Insert
eyebolt
(A, figure 3)
thru.iug
on blade and
screw on 5/16 nut (B) only far enough
so
that it is
flush with the end of the
eyebolt.
4. Hook the spring (C) into the pivot frame (D).
Stretch the spring with a pliers to hook springs on
eyebok (A).
5. Repeat steps 3 and 4 for the other spring
6.Tighten the nut (B) on both eyebolts down to
expose about
3/4”
(19 mm) of thread.
?.Add the other nut (E) to each
eyebolt.
Hold the
first nut (B) secure with a wrench and tighten the
second nut (E) securely on each
eyebok.
Figure 3. Tension Springs
A.
Eyebolt
D. Pivot Frame
0. Nut,
5116
E. Nut,
5/16
C. Spring
