PART NO. DESCRIPTIONREF NO. QTY.
Pump Drive Group
Footnotes
WELD, ARM, PUMP DRIVE IDLER - ORG 1 5046430CSM 1
BUSHING, BRASS, 1.25X1X1.25 2 5022157SM 2
SPACER, .39 X 1.00 X 2.55 3 5045135SM 1
WASHER, .41 X 1.75 X .14 4 5025305SM 2
BOLT, 3/8-16 X 3-1/2 GD5 YZ 5 5025013X28SM 1
NUT, 3/8-16 HEX NYLOCK FLANGE 6 5025394SM 3
BOLT, 3/8-16 X 2-1/4 GD5 YZ 7 5025013X18SM 1
BOLT, 3/8-16 X 1-3/4 GD5 8 5025013X14SM 1
NUT, 3/8-16 HEX SIDE LOCK 9 5025100SM 1
WASHER, 3/8 GD.9 FLAT 10 5025293SM 1
PULLEY, FLAT IDLER, 4.06 X .75 W 11 5101380SM 1
SCREW HOOK, 3/8-16 X 4-1/4 12 5025321SM 1
NUT, 3/8-16 HEX 13 5025034SM 2
SPRING, EXTENSION, SWIVEL END 14 5022847SM 1
PULLEY, PUMP DRIVE 15 5100912SM 2
KEY, 5MM SQ. W/ RADIUS 16 5023254SM 2
WASHER, .265 X 1.50 X .109, YZ 17 5044577SM 2
CAPSCREW,HEX HEAD M6-1.0X 14MM 18 5023215SM 2
SET SCREW, 5/16-24 X 3/8, KNURL, W/PATCH 19 5025437SM 4
BELT, #7-9502 20 5100923 1
PULLEY, CRANKSHAFT 21 5100914SM 1
The above parts group applies to the following Mfg. Nos.:
13
2009Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
5900707 - ZT4000B24
5900765 - ZT4000B26
TP 400-7340-M-50-S
