PART NO. DESCRIPTIONREF NO. QTY.
Hydraulic Group
Footnotes
ADAPTER, HYD. 1 5022633SM 2
FITTING, #8 JIC - #8 O-RING, 45 DEG. 2 5023338SM 4
ADAPTER, 90 DEG, 9/16-3/8 BARB 3 5023267SM 2
FITTING, TEE, 1/2 HOSE 4 5022920SM 2
ADAPTER, 90 DEG, 9/16-5/8 BARB 5 5023346SM 1
ADAPTER, 45 DEG, 9/16-3/8 BARB 6 5023461SM 3
FITTING, #8 JIC - #8 O-RING, 90 DEG. 7 5022599SM 2
HOSE, 3/8" PUSH-LOCK, 18.50" 8 5050860X18P5SM 1
HOSE, 3/8" PUSH-LOCK, 6.50" 9 5050860X6P5SM 2
HOSE, 3/8" PUSH-LOCK, 6.00" 10 5050860X6SM 2
NUT, 3/8-16 HEX SERRATED FLANGE 11 5025128SM 4
HOSE, 3/8" PUSH-LOCK, 19.00" 12 5050860X19SM 1
HOSE, 5/8 PUSH-LOCK, 24.50" 13 5050933X24P5SM 1
HOSE ASSEMBLY (25") 14 5023370SM 2
HOSE ASSEMBLY (21) 15 5022711SM 2
CAP, HYDRAULIC 16 5101267SM 1
TANK, HYDRAULIC, ASSEMBLY (Includes Ref. Nos 21,22,23, and 24.) 17 5061712SM 1
CLAMP, #4 HOSE, STAINLESS 18 5022922SM 1
CLAMP, #10 HOSE, STAINLESS 19 5021164SM 2
CLAMP, HOSE 20 5023268SM 11
FITTING, ELBOW, 3/8" 21 5023118SM 1
GROMMET 22 5023120SM 1
GROMMET 23 5023121SM 1
FITTING, ELBOW, 5/8" 24 5023119SM 1
MOTOR, WHEEL (Includes Ref. Nos 27 and 28) 25 5023316SM 2
BOLT, 3/8-16 X 1-1/4 GD5 26 5025013X10SM 4
KEY (SV) 27 5022042X2SM 2
NUT, CASTLE, 1-20 (SV) 28 5022042X3SM 2
PE, 10CC HYDRAULIC PUMP - LH 29 5101404 1
PE, 10CC HYDRAULIC PUMP - RH 30 5101403 1
FILTER HEAD, HYDRAULIC 31 5023096SM 1
FILTER, OIL 32 1719168SM 1
BOLT, 1/4-20 X 3/4 GD5 YZ 33 5025010X6SM 2
WASHER, 1/4 SAE 34 5025154SM 2
WASHER, 1/4 LOCK 35 5025169SM 2
PIN, COTTER, 1/8 X 2 36 5025203X16SM 2
The above parts group applies to the following Mfg. Nos.:
19
2009Copyright © by Briggs and Stratton Corporation
Briggs and Stratton Yard Power Products Group
Milwaukee, WI, USA. All rights reserved
5900707 - ZT4000B24
5900765 - ZT4000B26
TP 400-7340-M-50-S
